Power

Input: DC 48-55V

Ethernet

8 * 10/100/1000M PoE Ports

2 * 10/100/1000M SFP Ports

Performance

Switching Capacity

20Gbps

Forwarding Rate

14.88Mpps

MAC Address

4K

Jumbo Frame

9216bytes

Transfer Mode

Store and forward

MTBF

100000 hours

Standard

Network protocol

IEEE802.3

IEEE802.3u

IEEE802.3ab

IEEE802.3z

IEEE802.3x

PoE Protocol

IEEE802.3af (15.4W)

IEEE802.3at (30W)

Industry Standard

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD)

EN61000-4-4 (EFT)

EN61000-4-5 (Surge)

Network Medium

10BASE-T: Cat 3, 4, 5 UTP(≤100 meter)

100BASE-TX: Cat5 or more UTP (≤100 meter)

1000Base-TX: Cat5 or more UTP/STP(≤100 meter)

Protection

Certificate

CE, FCC, RoHS

Environment

Environment

Working Temperature: -40~75°C

Storage Temperature: -40~85°C

Working Humidity : 10%~90%, non-condensing

Storage Temperature: 5%~90%, non-condensing

Working Height: Maximum 10, 000 feet

Storage height: Maximum 10, 000 feet

Physical Features

Dimension

Product Dimension (L*W*H): 160*135*44mm

Package Dimension (L*W*H): 242*207*86mm

N.W: 0.73kg

G.W: 0.90kg

Packing Info

Carton MEAS: 445*445*510mm

Packing Qty: 20 units

Packing Weight:  19KG

Power Voltage

Input Voltage: DC 48-55V

Type of input: 4 PIN Industrial Terminal(block V1+V1- V2+ V2-)

Package List

Switch 1 pcs, Pull-arm 1 pair, User manual 1 pc, Certification 1 pc

Indicators

PWR(power supply)

Lighting: Powered

Un-Light: No Power

1-10 Green(Link&Data)

Lighting: Connecting

Flashing: Data Transmit

Un-Light: Disconnect
