Product name

6 ports Gigabit Industrial PoE Switch

Model

HR600-AFG-42S

Connector Type

4*gigabit PoE Ports + 2*gigabit SFP ports

Network Protocols

IEEE802.3

IEEE802.3i

IEEE802.3u

IEEE802.3ab

IEEE802.3z

PoE Parameters

PoE Standard: IEEE802.3at (30W) and IEEE802.3af (15.4w)

Each port Max: 15.4 W (IEEE 802.3af)

Each port Max: 30 W (IEEE 802.3at)

PoE compatibility: IEEE 802.3af/at adaptive

PoE port output: DC 52V

PoE power supply core: 1/2+ ; 3/6-

Network Media

10BASE-T: Cat5 UTP(≤100 m)

100BASE-TX: Cat5 or more UTP(≤100 m)

1000BASE-TX: Cat5 or more UTP(≤100 m)

Fiber Media

Multi-mode: 850nm, 1310nm  transmission distance: 550m/2Km

Single-mode: 1310nm, 1550nm  transmission distance: 20/40/60/80/100/120Km

LED indicator

PWR

Lighting: Powered

Un-Light: No Power

Port Yellow

Lighting: 1000M connecting

Un-Light: 10M/100M connecting

Port Green

Lighting: Connecting

Flashing: Data Transmit

Un-Light: Disconnect

FX1, FX2

Lighting: Fiber optic connecting

Un-Light: Fiber optic disconnecting

Quick flash: Data Transmit

Power Supply

Power input: DC52V (48～55V)

power supply wiring:  3 PIN terminal block（V+ V- V+）

Working Environment

Operating Temperature:  -40～85℃

Storage Temperature:  -40～85℃

Humidity:  5%~95 %( non-condensing)

Industry Standard

EMI:  FCC Part 15,  CISPR (EN55032) class A

EMS:  EN61000-4-2 (ESD)

EN61000-4-4 (EFT)

EN61000-4-5 (Surge)

Mechanical Structure

Shell protect grade:  IP40

Installation: DIN rail

N.W: 0.5 KG  G.W: 0.77 KG（without power supply）

Product Dimension (L×W×H): 145mm×125mm×40mm

Package Dimension(L×W×H):  250mm×210mm×65mm

Carton Box Dimension(L×W×H): 608mm×500mm×435mm

Packing Quantity: 36 (PCS)

Package Contents

Industrial Switch: 1 unit

User Guide: 1unit

Certificate warranty card: 1unit

Certification

CCC , FCC, RoHS

MTBF

100, 000 hours

Warranty

5 years

Hardware parameter

Bandwidth

12Gbps

Cache

1M

Chipset

88E6161

Package Forwarding Rate

8.928Mpps

MAC address

2K

Forwarding mode

Store-and-forward
