4* Gigabit PoE Ports (Port 1 supports 90W)

2* Gigabit SFP Port

IEEE802.3

IEEE802.3i

IEEE802.3u

IEEE802.3ab

IEEE802.3z

PoE
standard: IEEE802.3af /IEEE802.3at

Single port max: 15.4 W (IEEE 802.3af)

Single port max: 30 W (IEEE 802.3at)

PoE
compatibility: IEEE 802.3af/at self-adaptive

PoE port output voltage: DC 48-55V

  PoE
power supply wire core:1/2+ ; 3/6-

EMI:
FCC Part 15, CISPR (EN55022) class A

EMS: EN61000-4-2 (ESD)

EN61000-4-4
(EFT) EN61000-4-5 (Surge)

10BASE-T: Cat3, 4, 5 UTP (≤100 m)

100BASE-TX:
Cat5 or above UTP (≤100 m)

1000BASE-TX: Cat5 or above UTP (≤100 m)

Working
temperature: -40～75℃

Storage temperature: -40～85℃

Humidity: 5%~95 %
(non-condensing)

Product dimension: 120*87*30 mm

Package dimension: 175*130*55mm

Product
N.W: 0.441 KG

  Product G.W: 0.530 KG (without power)

Carton MEAS: 540*290*375mm

Packing Qty: 40 PCS

  Packing Weight: 22.2 KG

1. Industrial Switch: 1 PC

2. User Manual: 1 PC

3. Certification: 1 PC

4. Pull-arm: 1 PC

LED Indicator

PWR, 1-6 green light

PWR

On: Powered on

Off: Powered off

1-6 green light

On: Link normal

Off: Link off

Flashing:
Link data transmitting

DIP function

V,
G, E (Up open, down close)

V

V:
VLAN mode, ports 1 to 4 are isolated and can communicate with ports 5 and 6

G

G:
Normal mode

E

E:
Extend mode, ports 1-4 are reduced to 10M and can be extended to 250m
