Product name

5 Ports 10/100M Intelligent Industrial PoE Switch

Model

HR500-AF-41

Connector Type

4*10/100M PoE ports + 1*10/100M RJ45 ports

Network Protocols

IEEE802.3

IEEE802.3i

IEEE802.3u

IEEE802.3ab

IEEE802.3z

POE Parameters

PoE Standard: IEEE802.3at (30W) and IEEE802.3af (15.4w)

Each port Max: 15.4W (IEEE 802.3af)

Each port Max: 30W (IEEE 802.3at)

PoE compatibility: IEEE 802.3af/at adaptive

PoE port output: DC 52V

PoE power supply core: 1/2+ ; 3/6-

Network Media

10BASE-T: Cat3, 4, 5 or more UTP(≤100 m)

100BASE-TX: Cat6 or more UTP(≤100 m)

1000BASE-TX: Cat5 or more UTP(≤100 m)

LED indicator

PWR
(Power supply)

On: Power On

Off: No Power

1-5 ports
(Green)

On: Connecting

Flashing: Data Transmit

Off: Disconnect

Power Supply

Power input:  DC48～55V

power supply wiring:  4 PIN terminal block (redundancy V1+V1-, V2+V2-); DC-IN 2.1mm

Working Environment

Operating Temperature: -40～75℃

Storage Temperature: -40～85℃

Humidity: 5%~95 %( non-condensing)

Industry Standard

EMI: FCC Part 15,  CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD)

EN61000-4-4 (EFT)

EN61000-4-5 (Surge)

Mechanical Structure

Shell protect grade:  IP40

Installation: DIN rail

N.W: 0.409KG         G.W:  0.489KG(without power supply)

Product Dimension (L×W×H): 119mm * 87mm * 28mm

Package Dimension (L×W×H): 175mm * 130mm * 55mm

Package Contents

Industrial Switch: 1 unit

User Guide: 1unit

Certificate warranty card: 1unit

Certification

CE,  FCC,  CCC,  RoHS

MTBF

100, 000 hours

Warranty

5 years

Hardware parameter

Bandwidth

1Gbps

Cache

448K

Chipset

IP175G

Package Forwarding Rate

0.744Mpps

MAC address1

K

Forwarding mode

Store-and-forward
