سوئیچ اترنت صنعتی اچ ار یو ای HRUI HR500-SW10811GS
برند:برند HRUI
دوسال تعویض
مشخصات
پورت اپلینگ
1 پورت 10/100M Uplink
پورت Ethernet
4 عددپورت اترنت 10/100Mbps
پورت SFP
1 پورت Uplink SFP
پهنای باند
5.6Gbps
توضیحات
سوئیچ اترنت صنعتی اچ ار یو ای HRUI HR500-SW10811GS
– سوئیچ 4 پورت اترنت 10/100Mbps و 1 پورت Uplink اترنت گیگ و 1 پورت Uplink SFP
– سوئیچ PoE صنعتی
– 48 ماه وارانتی بی قید و شرط (24 ماه گارانتی تعویض + 24 ماه گارانتی تعمیر)
| Power | DC 12～55V |
| Ethernet | 8 100M RJ45 Port
1 Gigabit Uplink Ports 1 Gigabit SFP Ports |
| Performance | |
| Bandwitdth | 5.6Gbps |
| Package Forwarding Rate | 4.166Mpps |
| MAC Address | 1K |
| Jumbo frame | 9.6Kbytes |
| Forwarding mode | Store and forward |
| MTBF | 100000 小时 |
| Standard | |
| Network Protocols | IEEE802.3
IEEE802.3u IEEE802.3z |
| Industry Standard | EMI: FCC Part 15, CISPR (EN55022) class A
EMS: EN61000-4-2 (ESD) EN61000-4-4 (EFT) EN61000-4-5 (Surge) |
| Network Media | 10BASE-T: Cat5 or more UTP(≤100 m)
100BASE-TX: Cat5 or more UTP(≤100 m) 1000BASE-TX: Cat5 or more UTP(≤100 m) |
| Fiber Media | Multi-mode：850nm，1310nm. transmission distance：550m/2Km
Single-mode：1310nm，1550nm. transmission distance：20/40/60/80/100/120Km |
| Certification | |
| Safety Certificate | CE、FCC、RoHS |
| Environmental standards | |
| Working Environment | Operating Temperature: -40～75℃
Storage Temperature: -40～85℃ Humidity: 5%~95 %( non-condensing) |
| Physical Specifications | |
| Specification Size | Product Size：138×108×44 mm
Packing Szie：245×190×60mm Product net weight: 0.567KG Product gross weight: 0.701 KG (excluding power supply) |
| Packing Info | Outer box size: 520×320×400mm
Packing quantity: 20 PCS Packing weight: 15.02KG |
| Voltage | Voltage input: DC12～55V
Power wiring: 4 PIN industrial terminals (redundant V1+V1-, V2+V2-) / DC 2.1 (DC 2.1 cannot be used together with V1 and V2) |
| Packing List | 1. Industrial switch: 1
2. Instructions: 1PCS 3. Qualification certificate, warranty card 1PCS 4. Mounting ears: 1 pair |
| Function indication | |
| LED Indicator | PWR, 1-8 Green, G10 |
| PWR | Lighting：Powered
Un-Light：No Power |
| 1-8 Green | Blinking slowly: 10/100 links are normal
Off: link failure Flash: link data transfer |
| G10 | Steady on: The optical fiber connection is normal
No light: no fiber connection Flash: link data transfer |
| DIP Funtion | V,G,E（Open Up, Close Down） |
| V | V：VLAN mode, ports 1-8 are isolated, and both communicate with ports 9 and 10 |
| G | G：Normal mode |
| E | E：In extension mode, ports 1-8 are reduced to 10M and can be extended to 250 meters |
