برند : برند HRUI
دستهبندی : تجهیزات شبکه
سوئیچ صنعتی اچ ار یو ای HRUI HR500-SW1050
پورت POE : 4 عدد
پورت اپلینگ : 1 پورت 10/100M Uplink
پهنای باند : 1 Gbps
سوئیچ صنعتی اچ ار یو ای HRUI HR500-SW1050
– سوئیچ 4 پورت 10/100M PoE و 1 پورت 10/100M Uplink
– سوئیچ PoE صنعتی
– 48 ماه وارانتی بی قید و شرط (24 ماه گارانتی تعویض + 24 ماه گارانتی تعمیر)
| Power | DC (12～55V) |
| Ethernet | 4* 10/100M Ethernet Ports
+ 1* 10/100M Ethernet Port |
| Chip | |
| Main Chip | IP175G |
| Performance | |
| Bandwidth | 1 Gbps |
| Packet Forwarding Rate | 0.744Mpps |
| Packet Cache | 448K |
| MAC Address | 1K |
| Jumbo Frame | 1536bytes |
| Forwarding Mode | Storage and Forward |
| MTBF | 100000 Hours |
| Standard | |
| Network Protocol | IEEE802.3 (Ethernet)
IEEE802.3u (Fast Ethernet) IEEE802.3x (Flow Control) |
| Industry Standard | EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD), EN61000-4-4 (EFT), EN61000-4-5 (Surge) |
| Network Medium | 10Base-T : Cat 3, 4, 5 or above UTP/STP(≤100m)
100Base-TX : Cat 5 or above UTP/STP(≤100m) |
| Certification | |
| Safety Certificate | CE, FCC, RoHS |
| Environment Standard | |
| Working Environment | Working Temperature: -40~75°C
Storage Temperature: -40~85°C Working Humidity ：10%~90%，non-condensing Storage Temperature：5%~90%，non-condensing |
| Physical Specification | |
| Dimension | Product Dimension: 100*76.5*30mm
Package Dimension: 175*130*55mm N.W：0.27 KG G.W：0.36 KG |
| Packing Info | Carton MEAS：540*290*375mm
Packing Qty：40 PCS Packing Weight: 15.4 KG |
| Power Voltage | Input Voltage ：DC 12-55 V
Type of input: 4 PIN Industrial Terminal (block V1+V1- V2+ V2-) |
| Package List | 1. Industrial Switch：1 PC
2. User Manual：1PC 3. Certification：1PC 4. Pull-arm : 1 PC |
| Function Indicator | |
| LED Indicator | PWR (Power Indicate)，1-5 Green Light（Link & Data) |
| PWR（power supply） | On: Power on
Off: Power off |
| 1-5 Green Light (Link & Data) | On: Link Connected
Flashing: Data Transmit Off: Link Disconnect |
