دستهبندی: تجهیزات شبکه
پورت آپلینگ 100: 8 عدد
پهنای باند: 20GBPS
پورت آپلینگ گیگ: 2 عدد
توان خروجی: 120
سوئیچ PoE گیگ اچ ار یو ای HRUI HR900-AFG-82N
برند:برند HRUI
دوسال تعویض
مشخصات
پورت آپلینگ 100
8 عدد
پهنای باند
20GBPS
پورت آپلینگ گیگ
2 عدد
توان خروجی
120
دارای
Watch dog
توضیحات
سوئیچ PoE گیگ اچ ار یو ای HRUI HR900-AFG-82N
– سوئیچ 8 پورت PoE گیگ و 2 پورت Uplink گیگ
– سوئیچ گیگ PoE
– 30 ماه وارانتی بی قید و شرط
– ایران کد 2233120766280050
| Power | AC INPUT (100-240 V) |
| Ethernet | 8* Gigabit PoE Ethernet Ports
2* Gigabit Uplink Ethernet Port |
| Chipset | 2*RTL8367S
RTL8238B |
| Performance | |
| Bandwidth | 20Gbps |
| Pack forward rate | 14.88Mpps |
| Memory cache | 448K |
| MAC address | 2K |
| Jumbo Frame | 9216bytes |
| Transfer mode | Storage & Forward |
| MTBF | 100000 Hours |
| Standard | |
| Network Protocol | IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX) IEEE802.3ab (1000Base-TX) IEEE802.3x (Flow control) |
| PoE Protocol | IEEE802.3af (15.4W)
IEEE802.3at (30W) |
| Industry Standard | EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD), IEN61000-4-5 (Surge) |
| Network Medium | 10Base-T : Cat3, 4, 5 or above UTP(≤100m)
100Base-TX : Cat5 or above UTP(≤100m) 1000Base-TX : Cat5 or above UTP(≤100m) |
| Certification | |
| Safety Certificate | CCC/CE/FCC/UL/ROHS |
| Environment Standard | |
| Working Environment | Working Temperature: -10~50 ℃
Storage Temperature: -40~70 ℃ Working Humidity: 10%~90%, non-condensing Storage Temperature: 5%~90%, non-condensing |
| Physical Specification | |
| Structure Size | Product Dimension: 220*161*44mmm
Package Dimension: 315*215*85mm N.W: 0.88kg G.W: 1.38kg |
| Packaging Info | Carton MEAS: 445*445*335mm
Packing Qty: 10 units Packing Weight: 14.8KG |
| Power Voltage | Input Voltage: AC 100-240 V 50-60Hz
Supply Power: 52V2.3A |
| Power Concumption | ＜30W |
| Package List | Switch 1 PC, Power cord 1 PC, User manual 1 PC, Certification 1 PC |
| Function Indicator | |
| Indicator | PWR (Power)，1-10 Green Light (Link&Data) |
| PWR | On: Powered on
Off: Powered off |
| 1-10 Green Light (Link&Data) | On: Link normal
Off: Link blocked Flashing: Data transmitting |
| DIP Switch | VLAN: Isolation mode. Ports 1 to 8 are isolated and communicate with the upstream interface. (enable POE watchdog)
Default: common mode, all interfaces can communicate with each other, the transmission distance is less than 100 meters, the transmission rate is 10/100/1000M adaptive; The port AI mode is disabled. Extend: Link extension mode, 7-8 ports force 10M, link 250M (enable POE watchdog) |
