برند : برند HRUI
دستهبندی : تجهیزات شبکه
سوئیچ PoE گیگ اچ ار یو ای HRUI HR900-AFG-42N
4 پورت
پورت آپلینگ اترنت گیگ : 2 عدد
پهنای باند : 1,2 GBPS
دارای : Watch dog
توان خروجی : 65
سوئیچ PoE گیگ اچ ار یو ای HRUI HR900-AFG-42N
– سوئیچ 4 پورت PoE گیگ و 2 پورت Uplink گیگ
– سوئیچ گیگ PoE
– توان کل 65 وات
– پشتیبانی پورت های 4-3 از قابلیت اکستند (Extend)
| Power | AC INPUT （100-240V） 50/60Hz |
| Ethernet | 4* Gigabit PoE ports
2* Gigabit Ethernet ports |
| Chip | RTL8367（5E19） |
| Performance | |
| Bandwidth | 12Gbps |
| Packet Forwarding Rate | 8.928Mpps |
| Package Cache | 1Mb |
| Mac Address | 2K |
| Jumbo Frame | 9216bytes |
| Forwarding mode | Store Forward |
| MTBF | 100, 000 hour |
| Standard | |
| Network Protocol | IEEE802.3 (Ethernet)
IEEE802.3u (Fast Ethernet) IEEE802.3ab(Gigabit Ethernet) IEEE802.3x (Flow control) |
| PoE Protocol | IEEE802.3af （15.4W）
IEEE802.3at （30W） |
| Industry Standard | EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD)、 EN61000-4-5 (Surge) |
| Network Media | 10Base-T : Cat3, 4, 5 or above UTP/STP(≤100m)
100Base-TX : Cat5 or above UTP/STP(≤100m) 1000Base-TX : Cat5 or above UTP/STP(≤100m) |
| Safety certification | CE、FCC、RoHS |
| Environment Standard | |
| Working Environment | Working temperature: – 10~50 ℃
Storage temperature: – 40~70 ℃ Working humidity: 10%~90%, non condensing Storage humidity: 5%~95%, non condensing |
| Physical Specification | |
| Structure size | Product size: 200* 118* 44mm
Package size: 245* 190* 60mm Product net weight: 0.61Kg Product gross weight: 0.91Kg |
| Packing information | Outer box size: 520* 320* 400mm
Packing quantity: 20 sets Packing weight: 19.2KG |
| Supply voltage | Input voltage: AC 100-240 V 50/60Hz
Power supply: 52V1.25A |
| Packing list | Switch, 1 PCS
Power cord, 1PCS Manual and certificate of conformity, 1 PCS |
| Functional indication | |
| PWR (Power light) | PWR(Power indication), Mode(DIP indication), 1-6 Green light(Link&Data) |
| PWR | On: Powered on
Off: Powered off |
| Mode | On：VLAN(Port isolation)
Off：Default(Normal mode) Flashing：Extend(Link extension) |
| 1-6 Green light | On：Link connection is normal
Off：Link not working Flashing：Data transmitting |
| VLAN | Port isolation: 1-4 ports realize isolation between the each port of the monitoring network and interworking with the uplink port to protect internet security. |
| Default | Normal mode, all ports communicate with each other, transmission distance is within 100 meters, transmission rate is 10/100/1000M self-adaptive |
| Extend | In the link extension mode, the 3-4 port PoE power supply and data transmission distance can be extended to 250 meters, and the transmission rate turns to 10 M |
